Key Features and Benefits
- Manual Operation: The bed is adjusted using hand cranks that fold away underneath the foot of the bed. This makes it a cost-effective option with reduced maintenance requirements compared to electric beds.
- Two Functions: The manual cranks allow for the adjustment of two sections:
- Backrest Adjustment: Can be raised to an angle of approximately 45-70 degrees to provide comfort and support for the patient.
- Legrest Adjustment: The leg section can also be adjusted, aiding in circulation and comfort.
- Durable Construction: The frame is made of epoxy-coated tubular steel, offering high resistance to corrosion, suitable for various environments.
- Mobility and Stability: The bed is mounted on four heavy-duty swivel casters (typically 125mm in diameter). Two of the casters have a total-lock brake system to ensure the bed remains securely in place when needed.
- Safety Features: The bed includes protective bumpers at all four corners and a sturdy, mesh-style sleeping surface that immobilizes the mattress.
Technical Specifications
| Feature | Detail | |
|---|---|---|
| Model Number | ZF-MA-19 (sometimes listed as ZF-M04-B or similar by suppliers) | |
| Type | Manual hospital bed (2 functions) | |
| Material (Frame) | Epoxy-coated tubular steel | |
| Sleeping Surface | Epoxy-painted steel mesh | |
| Approx. Dimensions (L x W) | 200 x (80-90) cm | |
| Fixed Height (w/o mattress) | ~50 cm | |
| Max Loading Capacity | Up to 250 KG (or 260kg depending on variant) | |
| Casters | 4 swivel casters, 2 with brakes (125 mm diameter) | |
| Mattress (Optional) | High-density polyurethane foam (11-12 cm thick), waterproof cover |
